RIO 425 AC Generator Interface

The RIO 425 is a dedicated interface module to allow parameters from an AC alternator to be displayed on the DCU and the Ethernet network.

Capable of integrating with voltages of 520VAC phase-phase, and up to 300VAC phase-neutral, plus phase currents, the unit also measures frequency, power factor and Total kW.

SKU: 1006409

  • Specifications

    The RIO 425 is a dedicated interface module to allow parameters from an AC alternator to be displayed on the DCU and the Ethernet network.

    Capable of integrating with voltages of 520VAC phase-phase, and up to 300VAC phase-neutral, plus phase currents, the unit also measures frequency, power factor and Total kW.

    Why more customers select the RIO 425

    The unit has easily configurable turn down ratio management for the required voltage and current transformers. Like all the Marine Pro units, the RIO 425 configures itself automatically when connected to the DCU, and can be configured independently if required.

    Class approved, with a simple display on the unit to assist troubleshooting, the RIO 425 makes the ideal accessory to the DCU in generating set applications.

    By being able to put AC parameters onto the DCU, the need for separate displays for these indications disappear. Simpler installation, no additional panels, integrated look and data management are key reasons why specifiers choose the RIO 425.

    Self configuring, installation and commissioning resources are greatly reduced, simplicity in configuring the unit for varying applications and voltages makes for reduced resources and skill sets during commissioning.

    The RIO 425 also places the parameters onto a data network that allows other ships systems to access these without dedicated converters, software and connections.
