Kessler Transfer Cases

Thousands of Parts in Stock, Ready to Ship

Palmer Johnson is a Kessler & Co authorized distributor. Kessler transfer cases are manufactured in Germany and are used in pieces of equipment all over the world with a growing market in North America. The Kessler transfer cases are offered in a 1 speed or 2 speed option. The 1 speed Kessler transfer cases are comprised by the series or type of W1000, W1400, W1600, W2000, W2400, W2500, W2550, W2600, W2700, and W3751. The 2 speed Kessler transfer cases are comprised by the series or type of VG1800, VG2450, VG2500, VG2600, VG2700, and VG3751

The Kessler transfer cases are used by some of the world's most trusted equipment manufacturer's including Grove, Faun, and Liebherr and are used in vehicles such as mobile cranes, heavy duty trucks, airport crash tenders and tow tractors.

Palmer Johnson has you covered no matter what your Kessler transfer case need is. Whether you are needing Kessler transfer case parts, a Kessler transfer case parts book, a Kessler manual, service and repair, a replacement transfer case, or simply want to talk to the experts to troubleshoot an issue with your Kessler transfer case; we’ve got you covered with it all. Contact us today!

Kessler Transfer Case Common Assembly Numbers

Kessler Transfer Case Type 3750 & W3751

Transfer Case Type	Kessler Transfer Case Part Number/Assembly Number	OEM	OEM Machine Number
W3750	W1280.2G	Liebherr	LTM 1300-1
W3750	W1340.2D	Liebherr	LTM 1400-1
W3750	W1340.2C	Liebherr	LTM 1400-1
W3751	W2394.2E	Faun	FA 041

Kessler Transfer Case Type VG1800

Transfer Case Type	Kessler Transfer Case Part Number/Assembly Number	OEM	OEM Machine Number
VG1800	W534.2B	Grove	KMK 5140

Kessler Transfer Case Type VG3750

Transfer Case Type	Kessler Transfer Case Part Number/Assembly Number	OEM	OEM Machine Number
VG3750	W1423.2C	Faun	FA 029
VG3750	W1423.2B	Faun	FA 029
VG3750	W1373.2C	Liebherr	MK 100
VG3750	W1373.2E	Liebherr	MK 100

Kessler Transfer Case Product Specs

Kessler 1 Speed Transfer Case Product Specs

Type	Ratio	Max Input Torque	Max Input Speed	Torque Distribution	Shaft Distance	PTO Option
W1000	1.37:1	10,000 Nm	4000 min-1	1:2	270 mm	No
W1400	1.10:1	10,000 Nm	3700 min-1	1:2	515 mm	No
W1600	1.00:1	16,000 Nm	2400 min-1	Rigid shaft engageable output	500 mm	No
W2000	1.03:1	20,000 Nm	2500 min-1	1:1	245 mm	No
W2400	1.00:1	25,000 Nm	3500 min-1	1:2	396 mm	No
W2500	1.03:1	25,000 Nm	2600 min-1	1:2	500 mm	No
W2550	0.97:1 0.86:1	33,000 Nm	2500 min-1	1:2 1:1	572 mm	No
W2600	0.97:1	30,000 Nm	2400 min-1	1:2 1:1	625 mm	No
W2700	0.75:1	33,000 Nm	2250 min-1	1:2 1:1	660 mm	Yes
W3751	0.80:1	40,000 Nm	2500 min-1	1:2 1:1	750 mm	Yes

Kessler 2 Speed Transfer Case Product Specs

Type	Ratio	Max Input Torque	Max Input Speed	Torque Distribution	Shaft Distance	PTO Option
VG1800	1.80:1 (1st Speed) 0.97:1 (2nd Speed)	18,000 Nm	2900 (3500) min-1	1:1 1:2	375 mm	No
VG2450	1.77:1 (1st Speed) 1.19:1 (2nd Speed)	20,000 Nm	3500 min-1	1:1 1:2	525 mm	No
VG2500	2.07:1 (1st Speed) 1.03:1 (2nd Speed)	31,000 Nm	2800 min-1	1:1 1:2	500 mm	No
VG2600	1.78:1 (1st Speed) 0.80:1 (2nd Speed)	33,000 Nm	2400 min-1	1:1 1:2	625 mm	Yes
VG2700	3.12:1 (1st Speed) 0.75:1 (2nd Speed)	30,000 Nm	2250 min-1	1:1 1:2	660 mm	Yes
VG3751	1.84:1 (1st Speed) 0.80:1 (2nd Speed)	40,000 Nm	2500 min-1	1:1 1:2	750 mm	Yes
