Air Cooled
Reduction ratio i= 2
Propeller rpm = motor rpm/i
- Motor with mounting brackets
- Vector control inverter IP65
- Anti ventilation / cavitation plate (incl. anode)
- Main switch and main fuse
- DC-DC converter 12 Vdc
- 1,5m cable for display, lever, key
- Quick install / easy connect / plug and play
- Leg SD25 by Yanmar
Optional:
- NMEA2000 compatible (upon request
| Product Code | Description | Motor Size | Nominal kW | Intermittent kW | Battery Vdc | Motor rpm |
| BV101966A | OutboardMaster 7A | 180-12 | 5 | 7 | 48 | 1500 |
| BV101978A | OutboardMaster 10A | 220-20 | 8 | 10 | 48 | 1500 |
| BV101977A | OutboardMaster 8A | 180-12 | 6 | 8 | 96 | 1500 |
| BV101500A | OutboardMaster 12A | 180-12 | 8 | 12 | 96 | 3000 |
| BV101988A | OutboardMaster 15A | 220-20 | 10 | 15 | 96 | 1500 |
| BV101999A | OutboardMaster 20A | 220-20 | 15 | 20 | 96 | 3000 |
Liquid CooledÂ
Reduction ratio i= 2
Propeller rpm = motor rpm/i
| Product Code | Description | Motor Size | Nominal kW | Intermittent kW | Battery Vdc | Motor rpm |
| BV101966W | OutboardMaster 10W | 180-12 | 8 | 10 | 48 | 1500 |
| BV101977W | OutboardMaster 15W | 220-20 | 10 | 15 | 48 | 1500 |
| BV101500W | OutboardMaster 18W | 180-12 | 12 | 18 | 96 | 3000 |
| BV101988W | OutboardMaster 25W | 220-20 | 20 | 25 | 96 | 3000 |
