Palmer Johnson is an authorized distributor for the Wichita AquaMaKKs Brakes and Clutches. The Wichita AquaMaKKs are water cooled clutches and brakes designed to provide accurate torque control for heavy-duty tensioning application. This Wichita AquaMaKKs series is available in 19“, 25”, and 36“ diameter sizes.
Whether you are needing genuine Wichita parts, service manuals or parts lists, or you are wanting one of our factory trained technicians to repair your Wichita AquaMaKKs Brake or Clutch; we’ve got you covered. Contact the Wichita Water Cooled Brake and Clutch experts today!
The Wichita AuqaMaKKs Brakes and Clutches are found in a wide array of applications including conveyors, cranes, and drawworks where they serve as a main brake that provides both parking and emergency stop braking functions.
| Common Model Number | Alternate Model Number | Assembly Number |
| Wichita Clutch KKB119AM | Wichita Clutch ATD KKB119AM | 7-119AM-W-1005 |
| Wichita Clutch KKB219AM | Wichita Clutch ATD KKB219AM | 7-219AM-W-1302 |
| Wichita Clutch KKB319AM | Wichita Clutch ATD KKB319AM | 7-319AM-W-1303 |
| Wichita Clutch KKB419AM | Wichita Clutch ATD KKB419AM | 7-419AM-W-1300 |
| Wichita Clutch KKB125AM | Wichita Clutch ATD KKB125AM | 7-125AM-W-1003 |
| Wichita Clutch KKB225AM | Wichita Clutch ATD KKB225AM | 7-225AM-W-1300 |
| Wichita Clutch KKB325AM | Wichita Clutch ATD KKB325AM | 7-325AM-W-1300 |
| Wichita Clutch KKB425AM | Wichita Clutch ATD KKB425AM | 7-425AM-W-1300 |
| Wichita Clutch KKB136AM | Wichita Clutch ATD KKB136AM | 7-136AM-W-1000 |
| Wichita Clutch KKB236AM | Wichita Clutch ATD KKB236AM | 7-236AM-W-1301 |
| Wichita Clutch KKB336AM | Wichita Clutch ATD KKB336AM | 7-336AM-W-1301 |
| Wichita Clutch KKB436AM | Wichita Clutch ATD KKB436AM | 7-436AM-W-1301 |
- Authorized Distributor
- Genuine Parts
- Service and Support
Wichita AquaMaKKs Brake & Clutch Product Features
- Durable air tube design with high strength reinforced neoprene air-tubes, offering longer service life
- Water channels for balanced water flow for the highest thermal capacity
- Long-lasting friction material with minimal wear on mating copper
- Copper alloy wear plates enable higher heat transfer than any other metals
- Hub spline provides perfect alignment of rotating discs
- External air & water connections
- Release springs ensure complete disengagement
- Adjustment for wear is easily accomplished by removing shims without any unit disassembly
- Unique torque pin column arrangement provides structural integrity of case
- Open case design with covers for safe, simple, visual inspection and easy maintenance
- All AquaMaKKs units are provided with a Marine protection package for enhanced durability in any operating environment
