The TR series Transfer cases are proven to supply power to both the front and rear axles and are available with various ratios, multiple speeds, axle disconnects, and built in differentials. Capacities are to 600 + horsepower. Accessory drive pads add flexibility to transfer case applications.
To read more about these products Download a brochure: TR2205 Transfer Case and TR221397 Transfer Case.
The Cotta TR2205 series features four identical input/output stations. This T-case is designed to provide both the highest number of possible configurations and lowest part count of any T- case on the market. A modular concept to accessories allows the addition or deletion of disconnects, pumps, pto’s and other options either in the field or on the production line. This minimizes inventory and maximizes application flexibility.
The Cotta TR1397 series is designed for direct mounting to the new Allison 4700 OFS series transmissions. Features include a flange and spline coupler for direct mounting to the Allison. Also featured are ground helical gearing, and a heavy duty case. The TR1397 is designed for severe service in both mobile and stationary equipment. Optional shaft disconnects can be added for the front axle, rear axle, or for use as pto’s. A remote version without the flange is also available.
